Download the F-LINE hydraulic fittings catalogue for configuration and dimensional reference, or use the shorter technical datasheet for specification and procurement.
A comprehensive configuration guide and dimensional reference, organised by fitting family. Includes tube connections, threaded transitions, adjustable fittings, welding, instruments, closures and spare components.
Download catalogue PDFA compact selection reference for procurement and project enquiries, with series identification, connection choices and the information required to confirm a fitting.
Download datasheet PDFIdentify a DIN 2353 connection by tube outside diameter, fitting series, thread and sealing form. A matching thread alone does not establish a correct connection.
Select the fitting, tube and seals as one assembly. Pressure capability depends on the exact configuration, material, tube dimensions, temperature and installation method.
Successful cutting-ring connections depend on suitable tubing, matched components, careful preparation and the correct assembly procedure for the supplied fitting system.
Send the configuration, tube size and series, all connection details, material and service conditions. Request an order-specific dimensional drawing and supporting documentation with your quotation.
Send the connection details and operating conditions. Fluidline can confirm the supplied configuration, availability and supporting documentation with your quotation.
Bring the whole assembly into your enquiry, from the connection and tube specification to the clamps that support the run.
Specify tube outside diameter, wall thickness and material with your fittings.
Explore tubing at Fluidline →
Include the tube diameter, mounting arrangement and support requirements.
Explore tube clamps at Fluidline →
Review tube preparation, component matching and inspection before assembly.
Read the installation overview →
